Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction for China Wholesale China Multicolor Screen Printer with UV Drying System, We can present you with one of the most competitive selling prices and good quality, because we have been much far more Qualified! So you should will not hesitate to call us.
Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction for China Screen Printing Machine and Screen Printer, Due to our good merchandise and services, we now have received good reputation and credibility from local and international customers. If you want more information and are interested in any of our items, make sure you feel free to contact us. We look forward to becoming your supplier in the near future.
Printing table size 1600mm×1000mm
Max material weight 50kg
Maximum material height 100mm
With 2-8 pcs print heads, it can print CMYK LC LM WV inks.
Equipped with professional printing board, can make the printer work more stably and efficiently.
Support 3D embossed effect printing, varnish glossy effect printing.
1600*1000mm, 5.25*3.28ft printing size can meet the printing needs of most customers.
The printing height can be customized, up to 40cm high.
Imported UV lamp, the service life can reach 10,000 hours.
Adopt white circulation system to make white printing smooth.
Adopt dual linear guides to ensure smooth and efficient operation of the print head.
Equipped with multiple emergency brake switches to ensure equipment safety.
Stable product quality: we are a professional manufacturer of UV printers for 13 years, with CE certificate and ISO9001 certification.
Independent R&D team: equipped with professional R&D team, to ensure that products are at the forefront of the industry.
Warranty period: one year warranty, excluding ink supply system, including print head, baffle, ink, ink line tube, etc.
Good after-sales service: 24-hour considerate after-sales service, free online training, video, manual, remote control.
Regular return visit service: return visit to old customers every three months, and track product usage.
| Product Model | YC1610H | |||
| Printhead Type | RICOH GH2220/TOSHIBA CE4/RICOH GEN5 Optional | |||
| Printhead Number | 2-8 heads | |||
| Ink Characteristics | UV Curing Ink (VOA Free) | |||
| Ink reservoirs | Refillable on the fly while printing / 1000ml per color | |||
| LED UV Lamp | more than 30000-hours life | |||
| Printhead arrangement | CMYKW V Optional | |||
| Printhead Cleaning System | Automatic Cleaning System | |||
| Guide Rail | Taiwan HIWIN | |||
| Working Table | Vacuum Sucking | |||
| Printing Size | 1600*1000mm | |||
| Print Interface | USB2.0 / USB3.0 / Ethernet Interface | |||
| Media Thickness | 0-100mm | |||
| Print Resolution & Speed | 720X600dpi | 4PASS | 4-16sqm/h | |
| 720X900dpi | 6PASS | 3-11sqm/h | ||
| 720X1200dpi | 8PASS | 2-8sqm/h | ||
| Life of printed image | 3 years (outdoor), 10 years (indoor) | |||
| File Format | TIFF, JPEG, Postscript, EPS, PDF etc. | |||
| RIP Software | Photoprint / RIP PRINT Optional | |||
| Power Supply | 220V 50/60Hz(10%) | |||
| Power | 3100W | |||
| Operation Environment | Temperature 20 to 30 ℃, Humidity 40% to 60% | |||
| Warranty | 12 months exclude the consumables | |||
Equipped with Japanese Epson DX5/DX7/XP600/TX800/I3200 heads with 180 nozzles 6 or 8 channels, which provides a high-precision printing.
Adopting HIWIN mute double linear guide rail which is high resolution, low noise and durable, to ensure the carriage moving smoothly, inks eject more stably.
Utilize high mute drag chain on X axis, ideal for protection of cable and tubes under high speed motion. With high performance, low noise, make the working environment more comfortable.
Sectional vacuum suction platform, easily choose the vacuuming sections, good for various sizes of personalized printing; With full cover for bleeding printing, it will improve the utilization of materials.
Adopting dual-level precision screw rod and imported Panasonic servo synchronous motors, ensure the screws rod on the both sides of Y axis synchronous running.
Equipped with self-researched cold drawn and high-strength aluminum beam, applied ultra strength aerial aluminum material, it ensures printing precision and stability, guarantee the perfect output.
Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction for China Wholesale China Multicolor Screen Printer with UV Drying System, We can present you with one of the most competitive selling prices and good quality, because we have been much far more Qualified! So you should will not hesitate to call us.
China Wholesale China Screen Printing Machine and Screen Printer, Due to our good merchandise and services, we now have received good reputation and credibility from local and international customers. If you want more information and are interested in any of our items, make sure you feel free to contact us. We look forward to becoming your supplier in the near future.
