Printing table size 2500mm
Max material weight 50kg
Maximum material height 100mm
| Product Model | YC2500HR | |||
| Printhead Type | RICOH GEN5/GEN6/KM1024I/SPT1024GS | |||
| Printhead Number | 2-8 units | |||
| Ink Characteristics | UV Curing Ink (VOC Free) | |||
| Lamp | UV LED lamp | |||
| Printhead Arrangement | C M Y K LC LM W V optional | |||
| Guide Rail | TAIWAN HIWIN/THK Optional | |||
| Working Table | Anodized aluminum with 4-section vacuum sucking | |||
| Printing Width | 2500mm | |||
| Coiled Media Diameter | 200mm | |||
| Media Weight | 100kg Max | |||
| Print Interface | USB2.0/USB3.0/Ethernet Interface | |||
| Media Thickness | 0-100mm, higher can be customized | |||
| Print Resolution & Speed | 720X600dpi | 4PASS | 15-33sqm/h | (GEN6 40% faster than this speed) |
| 720X900dpi | 6PASS | 10-22sqm/h | ||
| 720X1200dpi | 8PASS | 8-18sqm/h | ||
| RIP Software | Photoprint / RIP PRINT Optional | |||
| Media | Wallpaper, flex banner, glass, acrylic, wood board, ceramic, metal plate, PVC board, corrugated board, plastic etc. | |||
| Media Handling | Automatic Release/Take Up | |||
| Machine Dimension | 4770*1690*1440mm | |||
| Weight | 2500kg | |||
| Safety Certification | CE Certificate | |||
| Image Format | TIFF, JPEG, Postscript, EPS, PDF etc. | |||
| Input Voltage | Single Phase 220V±10%(50/60Hz,AC) | |||
| Working Environment | Temperature: 20℃-28℃ Humidity: 40%-70% RH | |||
| Warranty | 12 months exclude the consumables related to ink, such as ink filter, damper etc | |||
Adopting gray level Ricoh stainless steel internal heating industry head which has high performance in speed and resolution. It is suitable for long-time working, 24 hours running.
More economical and environmental than mercury lamp, material adaptability more widely, energy saving and life longer (up to 20000 hours).
Adopt big steel roller to guarantee the materials not wrinkled or off track, realize the quantitative production.
Extra-wide and ultra-high precision printing platform.
Adopting heating outside for the printhead to keep the ink fluency all the time.
